LTL101AL06-803
LTL101AL06-803 Grunnupplýsingar
| Panel Model | LTL101AL06-803 |
|---|---|
| Panel Vörumerki | SAMSUNG |
| Lýsingu | a-Si TFT-LCD ,10.1 inch, 1280×800 |
| Pallborðsgerð | a-Si TFT-LCD |
| LTL101AL06-803 Verð | Beðið um verð og leiðtíma |
| Vinnuhitastig | 0 ~ 50 °C |
| Geymslu hiti | -20 ~ 60 °C |
LTL101AL06-803 Vélrænni eiginleikar
| Punktarupplausn | 1280(RGB)×800 (WXGA) |
|---|---|
| Pixel Configuration | RGB Vertical Stripe |
| Pixel Density | 149 PPI |
| Stærðarhlutföll | 16:10 (H:V) |
| Formþáttur | Flat Rectangle Display |
| Dot Pitch | 0.0565×0.1695 mm (H×V) |
| Pixel Pitch | 0.1695×0.1695 mm (H×V) |
| Virk svæði | 216.96×135.6 mm (H×V) |
| Holur og sviga | Without |
| Landslag eða Portrait | Landscape type |
| Snertiskjár | Without |
LTL101AL06-803 Optical Features
| Skjástilling | PLS, Normally Black, Transmissive |
|---|---|
| Andstæðahlutfall | 900 : 1 (Typ.) (Transmissive) |
| Sýna lit. | 16.2M (6-bit + FRC) |
| Litur Gamut | 50% NTSC (CIE1931) |
| Viðbragðstími | 30 (Typ.)(Tr+Td) |
| Skoða horn | 80/80/80/80 (Typ.)(CR≥10) (L/R/U/D) |
| Skoða stefnu | Symmetry |
| Sólskin læsileg | N |
LTL101AL06-803 Electronics Lögun
| Lóðrétt tíðni | 60Hz |
|---|---|
| Reverse Scan | No |
LTL101AL06-803 Backlight System
| Lampapunktur | Edge light type |
|---|---|
| Lampategund | WLED |
| Gerð tengi | Included in panel signal interface |
| Lamp Driver Board | No |
LTL101AL06-803 Signal Interface
| Merki Flokkur | LVDS |
|---|---|
| Merkisflokkur | LVDS (1 ch, 8-bit) |
| Input Voltage fyrir Panel | 3.3V (Typ.) |
| Gerð tengi | Connector |
